| MODEL |
AL1200AAH |
AL2500AAH |
| Process Dimension |
Processing dimensions (WxHxT) |
1,200X1,240X90T |
2,500X1,240X90T |
| Power |
Saw (controllable rpm) |
Main axis saw (RPM control) |
10HP (0~4500RPM) |
10HP (0~4500RPM) |
| Moving Stopper |
adae |
Servo 1.5HP 180w |
Servo 1.5HP 180w |
| Safety |
safety device |
Emergency Stop Button Beam |
Emergency Stop Button Beam |
| Dimension of Machine |
Body (WxLxH) |
2,500X2,350X1,650 |
3,900X2,350X1,650 |
| Electrical Power |
Power used |
380V/60Hz(3Ø,4wires) |
380V/60Hz(3Ø,4wires) |
| Operation |
Job control |
OP/Touch Panel |
OP/Touch Panel |
| Functions |
Operation function |
Running Saw,Auto,Manual |
Running Saw,Auto,Manual |
| Clamper Type |
clam |
Rackgear Type |
Rackgear Type |
※ Product specifications vary depending on order.
